Lawyer Calibration
Technical characteristics
Weighing range 20g ~ 600g
Accuracy ±3g
Speed 25,000 pieces/hour
Display 10.5-inch touchscreen
PLC controller
Power 4.1 kW
Dimensions ≤ 21000 mm (L) × 1500 mm (W)
Mango calibration line
Washer
Gentle cleansing with controlled agitation for sensitive fruits
-
Machine Type: Bubble Wash Tub
-
Dimensions: 3000 × 600 × 1448 mm (L × W × H)
-
Useful volume: 2.45 m³
-
Material: Fully welded stainless steel (structure, tank and conveyor)
-
Swirl system: Bubble generator integrated under the tank, allowing controlled agitation which removes impurities without damaging the product
-
Product extraction: By roller elevator, allowing row-by-row evacuation
-
Installed power: 2.75 kW
-
Variable speed drive: Schneider inverter for fine adjustment of the flow
A reliable solution for pre-treating sensitive fruits, while guaranteeing hygiene and performance.
Brusher / Dryer
Gentle cleaning and drying for a flawless finish
-
20 brushes arranged under 4 blower groups ensure efficient drying after washing.
-
Brush diameter: 125 mm
-
Material: Extra soft nylon, to preserve the appearance of delicate fruits.
-
Blower: 5 groups – 10 fans in total
-
Fan type: Axial flow for high efficiency
-
Lower collection tray for water recovery (belly pan)
Ideal for products with delicate surfaces, while maintaining a fast and consistent sorting flow.
Inspection table
Simple and effective visual quality control at the end of the line
-
Placed after the drying module, the inspection table allows operators to identify and remove fruit of insufficient quality.
-
PVC strip structure: smooth, hygienic and easy to clean surface
-
Dimensions: 4000 × 800 × 1500 mm (L × W × H)
-
Power consumption: 0.5 kW
-
Ideally designed for 1 to 3 operators per station depending on the width
An essential link to guarantee final quality before packaging.
1 channel with foam table (6 outputs)
Simple and precise sorting with respect for the product at each stage
-
Sorter type: 1-lane
-
Capacity: 20,000 pieces/hour
-
Sorting accuracy: ±2g
-
Number of exits: 6 side exits, with integrated foam packing table at each chute to avoid shocks on the mangoes
-
Conveying system: V-shaped conveyor to guide the mangoes smoothly to the weighing cell
-
Sorting principle: Automatic classification from lightest to heaviest weight
-
Dimensions: (to be completed according to your exact model)
A compact and efficient solution for medium production, guaranteeing reliable weight sorting and gentle handling of sensitive fruit.
2 lines, 12 outputs
High-speed automatic sorting for industrial performance
-
Sorter type: 2-lanes
-
Capacity: 50,000 pieces/hour
-
Sorting accuracy: ±5g
-
Number of outputs: 12 weight gauges, with green foam receiving tables for gentle packaging
-
Operating principle:
Computer-controlled electronic sorting, based on the individual weight of each fruit.
The system includes: weighing assembly, drop unit, collection unit. -
Bilateral exits:
Optimizes working speed
Gives operators more time for packaging
Designed for high speeds, this sorter offers high-precision sorting, excellent product flow management, and optimized working comfort for operators.
Do you have a specific need?
We design a tailor-made solution, perfectly adapted to your product and your organization.
At MCS Process, we adapt our sorting machines according to your production volume, your technical constraints and your available space.
Our machines can be configured with 1 to 4 channels, a variable number of outputs, and integrated with other add-ons.
